Specifications
Electrical Specifications
Characteristic frequency: Resistor absorber crossover frequency.
Model 5402 Model 5405 Model 5407 Model 5411
Frequency Range: RE TESTS1
9 kHz–5 GHz
RI TESTS
DC – 20 GHz RE TESTS1
9 kHz–5 GHz
RI TESTS2
DC – 20 GHz RE TESTS1
9 kHz–5 GHz
RI TESTS2
DC – 20 GHz RE TESTS1
9 kHz–5 GHz
RI TESTS2
DC – 20 GHz
VSWR (Typical): Characteristic
frequency:
 1.75:1
All other
frequencies:
 1.50:1
Characteristic
frequency:
 1.75:1
All other
frequencies:
 1.50:1
Characteristic
frequency:
 1.75:1
All other
frequencies:
 1.50:1
Characteristic
frequency:
 1.75:1
All other
frequencies:
 1.50:1
Maximum CW
Input Power: 100 W 250 W
400 W
with optional blower 200 W
500 W
with optional blower 1000 W
Input Impedance: 50 Ω 50 Ω 50 Ω 50 Ω
Feed Connector
Type: CW
7/16 DIN plug to
N jack adaptor CW
7/16 DIN plug to
N jack adaptor CW
7/16 DIN plug to
N jack adaptor CW
7/16 DIN plug to
N jack adaptor
Shielding
Effectiveness: From internal
E-fields:
80 dB minimum
10 kHz–1 GHz From internal
E-fields:
80 dB minimum
10 kHz–1 GHz From internal
E-fields:
80 dB minimum
10 kHz–1 GHz From internal
E-fields:
80 dB minimum
10 kHz–1 GHz
1
Frequency range where OATS correlation demonstrated
2
Low VSWR to f  20 GHz; performance dependent on field uniformity tolerance
