Fig. 9, Purlin assembly – EFCO S5600 Slope Glazed User Manual
Page 11
EFCO CORPORATION 6/2012 PART NO. Y308
Page 11 of 23
Series 5600 Slope Glazed Curtain Wall Installation Instructions
Section V: Purlin Assembly
Purlin Assembly
B.)
Snap-on purlin retainer clips at each end of purlin as shown. (Ref. Figs. #9 & 10)
[FIG. 9]
Lay a bed of sealant in
notch on rafter prior to
setting horizontal purlin.
Aluminum purlin retainer clips
