Torque Module Installation and User Guide for Model 250i Dynamometers
C H A P T E R 1
Introduction
1-2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INTRODUCTION
The Torque Module, when added to Dynojet's market leading inertia dynamometer,
results in a complete vehicle performance test.
C ONVENTIONS U SED I N T HIS M ANUAL
The conventions used in this manual are designed to protect both the user and the
equipment.
T ECHNICAL S UPPORT
For assistance, please contact Dynojet Technical Support at 1-800-992-3525, or write
to Dynojet at 2191 Mendenhall Drive, North Las Vegas, NV 89081.
Visit us on the World Wide Web at www.dynojet.com where Dynojet provides state of
the art technical support, on-line shopping, 3D visualizations, and press releases
about our latest product line.
P ARTS L IST
The following table lists all of the parts included in the Torque Module Installation kit
(P/N 73920005). Check your kit against the parts listed to make sure you have
received all of the parts. If any part is missing, contact Dynojet Technical Support.
Example of Convention Description
The Caution icon indicates a potential hazard to the
dynamometer equipment. Follow all procedures
exactly as they are described and use care when
performing all procedures.
The Warning icon indicates potential harm to the
person performing a procedure and/or the
dynamometer equipment.
Bold Highlights items you can select on in the software
interface, including buttons and menus.

The arrow indicates a menu choice. For example,
“select File  Open” means “select the File menu,
then select the Open choice on the File menu.”
part number description quantity
35430899 Weight, 25 pounds 4
61319001 Calibration Arm Assembly 1
66114002
or
66104001
Torque Module Sub-Assembly
or
Torque Module High Resolution Sub-Assembly
1
76950503 Cable, Torque Cell 1
