Dynojet 250i: Torque Module - Manual (Page 41)

Torque Module Installation and User Guide for Model 250i Dynamometers
Index-i
I
NDEX
A
accessing dyno electronics 1-10
B
battery ground cable 1-7, 1-20
belleville washers 1-4, 1-19
brake cover
removing 1-7
replacing 1-20
C
cable clamp 1-15
calibration arm 2-3, A-3
number 2-3, A-3
weights 2-5, A-6
carriage assembly bulkhead 1-14
carriage clamps 1-5, 1-18
conventions 1-2
D
document part number 1-1
drum bulkhead 1-14
dyno electronics
accessing 1-10
cable clamp 1-15
dyno top cover
removing 1-6
replacing 1-17
E
eddy current brake cover
removing 1-7
replacing 1-20
L
load cell
installation 1-4–1-16
routing the cable 1-14
M
main breaker location 1-3
N
nut block 1-5, 1-18
P
parts list 1-2
power
connecting and disconnecting 1-3
main breaker location 1-3
R
routing the load cell cable 1-14
S
screw support bracket 1-4, 1-19
T
technical support 1-2
tire carriage
belleville washers 1-4, 1-19
carriage clamps 1-5, 1-18
nut block 1-5, 1-18
removing 1-4
replacing 1-18
screw support bracket 1-4, 1-19
torque cell calibration 2-2–2-7
calibration arm 2-3, A-3
calibration number 2-3, A-3
calibration weights 2-5, A-6
torque gauge 2-7, A-8
torque module
installation 1-12–1-16
W
WinPEP 6 A-1
WinPEP 7 2-1
Z
zero calibration 2-2, A-4
