6 Document #98111100
For example:
Plug Fires Every: 720
Typical for a four cycle engine with the pickup
on a spark plug wire. (Refer to the RPM Pickup
section of Chapter 4 in the WinPEP User Guide
for more information.)
RPM Redline : 10
For a redline at 10,000 RPM.
Tire Speed Rating: 120
For a Speed redline at 120 MPH.
Max Tire Temp: 180
Scales the Tire Temp. Gauge for a danger
indication at 180 degrees.
Step 3
Select Steps from the option menu to select the
step size of the Braking Target for each gauge.
Step 4
The Options Menu allows the user to choose the
Active Braking Gauge or the user can use the
mouse and click on the gauge to make it active or
use the Tab key to toggle through them.
