47

System Real-time Messages

Status

Description

1111 1000

Timing Clock

1111 1010

Start – starts the sequencer from step 1

1111 1011

Continue – re-starts the sequencer from the current step

1111 1100

Stop – Stops the sequencer



Universal System Exclusive Message (Device Inquiry)

Status

Description

1111 0000

System Exclusive (SysEx)

0111 1110

Non-realtime message

0vvv vvvv

If MIDI channel is set to 1-16, 0vvvvvvv must match (unless MIDI Channel
= ALL); always responds if 0vvvvvvv = 0111 1111.

0000 0110

Inquiry Message

0000 0001

Inquiry Request

1111 0111

End of Exclusive (EOX)



Poly responds with:

Status

Description

1111 0000

System Exclusive (SysEx)

0111 1110

Non-realtime message

0vvv vvvv

If MIDI Channel = ALL, 0vvvvvvv = 0111 1111. Otherwise 0vvvvvvv =
Channel Number 0-15.

0000 0110

Inquiry Message

0000 0010

Inquiry Reply

0000 0001

DSI ID

0010 0001

Poly Evolver ID (Family LS)

0000 0000

Family MS

0000 0000

Family Member LS

0000 0000

Family Member MS

0jjj nnnn

Main PIC Software version: jjj – Major rev; nnnn – Minor Rev

0jjj nnnn

Voice PIC Software version: jjj – Major rev; nnnn – Minor Rev

0vvv vvvv

DSP Software version LS

0vvv vvvv

DSP MS

1111 0111

End of Exclusive (EOX)
