25
Shape: see table Selects the LFO waveshape:
Display LFO Shape
Triangle Triangle
Rev Saw Reverse Sawtooth
Sawtooth Sawtooth
Square Square Wave
Random Random – changes once per cycle for
sample-and-hold effects
Amount: 0…100; Ksync 1…100 Sets the amount of LFO. An new feature
on the Poly is the ability to re-start the LFO when a new note is played (Key Sync). To
select this mode of operation, set the LFO amount to a value over 100. Each LFO can
be set independently.
Dstination: see table LFO 1 destination - see the Modulation
Destination table on page 34 for a list of possible destinations.
Page 10:
LFO 2
Page 11:
LFO 3
Page 12:
LFO 4
These LFOs screens are the same as LFO 1
Page 13:
Envelope 3
Amount: -99…+99 Amount of envelope 3
Dstination: see table Envelope 3 destination - see the Modulation
Destination table on page 34 for a list of possible destinations.
Velocity: 0…100 Amount of MIDI velocity controlling the level envelope 3.
Delay: 0…100 Delay time of Envelope 3, prior to Attack
Attack: 0…110 Attack time of ADSR envelope generator 3
Decay: 0…110 Decay time
Sustain: 0…100 Sustain Level
Release: 0…110 Release time
