26 r1 p, Hanging door panels, Caulk – Coral Industries 6000 Bypass with BTB Towel Bar - 26R1-P (If Purchased from a Plumbing Wholesaler – Most Common) User Manual
Page 8: Cg a

26R1P 11/10
the use of a caulking compound will assure a water-tight
seal. seal unit by applying caulk along outside edge of
enclosure where metal and bath meet, especially where
sill meets tub.
if desired, caulk inside of enclosure where jambs meet
walls.
lift door panel into header with towel bar facing inside
of bath. seat rollers on roller track while guiding bottom
of door into sill guide.
Repeat for remaining door, hanging panel with towel bar
facing outside of bath.
adjust rollers up or down as needed in roller fin slots to
compensate for out-of-plump conditions, allowing panels
to hang straight.
13
Hanging Door Panels
14
caulk
26
R1
P
inside
door
Panel
outside oF
bath
header
c
inside
door
Panel
outside
door
Panel
outside oF
bath
tub
header
guide
sill
c
g
a
outside oF bath
caulk
caulk
