Jambs, Bumpers, Header – Coral Industries 6000 Bypass with BTB Towel Bar - 26R1-P (If Purchased from a Plumbing Wholesaler – Most Common) User Manual
Page 6: Ab b

26R1P 11/10
Reposition jambs on tub and mount to wall using pan head
screws (i) - 8a x 1 1/4 " pan head screws for 901 jambs, 8a x 2"
pan head screws for 531 jambs.
mount bumpers (h) in top and bottom holes.
lower header over jambs until seated squarely on legs of
both jambs.
secure header to jambs by drilling a 1/8" hole through header
into jambs on inside of tub near wall.
attach header to jambs using 8a x 3/8" pan head self drilling
screws (n).
measure from wall to wall (over the top of both jambs) and
cut header (c) to that measurement.
7
Jambs
(B)
/ Bumpers
(H)
8
Header
(c)
9
Header
(c)
i
8a x 1 1/4" or
8a x 2"
Pan head screw
b
bumper
h
jamb
sill
a
outside oF bath
jamb
jamb
measure
outside oF bath
sill
a
b
b
header
c
n
8a x 3/8" Pan
head self drill-
ing screw
b
jamb
inside oF bath
