2CC1-GP 3/07
Before starting installation of your new enclosure, carefully read all instructions
and lay out parts to become familiar with their identity.
USE OF ANCHORS
Anchors are furnished with every enclosure. However, the use of anchors is not recommended when attaching your enclosure
to a fiberglass unit or wall surround with board reinforced mounting areas. Mounting holes in this case should be drilled with
an 1/8" drill bit.
Mounting this unit on tile requires the use of anchors. Special care must be taken not to crack the tile. Before drilling holes in
the tile, lightly chip glazed surface of tile at the desired locations. Drill holes using a 3/16" masonry drill bit. Insert anchors into
the holes making certain that ring on large end of anchor meets the surface of the tile.
CLEANING
SEALING
The use of a caulking compound can assure a water-tight seal when applied along outside edge of the enclosure where metal
and bath meet. If desired, caulk inside of enclosure where jambs meet walls.
C leaning and care of your enclosure is important to its lasting beauty. A nonabrasive liquid cleaner is recommended.
Never use scouring powder or pads.
Do not try to cut the mirrors or glass used in this enclosure.
Tempered glass and mirrors will disintegrate if cut.
1/8" Drill Bit
3/16" Drill Bit
(3/16" Masonry Bit for
Ceramic Tile)
Scratch Awl
Measuring Tape
Hacksaw
Phillips Screw Driver
Caulking Compound
File
Drill
Level
Masking Tape
PARTS LIST
TOOLS
NEEDED
A SILL A609 1
B JAMB A605 2
C HEADER A631 1
E VINYL TRACK GUIDE V437 1
D TOWEL BAR A711 2
F ANCHOR H002 6
G BUMPER H100 2
H ROLLER H342 4
I 8-32 X 3/8 TRUSS HEAD SCREW H430 4
J 8A X 3/8 TRUSS HEAD SCREW H470 2
K 8A X 1 1/4 PAN HEAD SCREW H480 6
N GUIDE HA91 1
O 8A X 3/8 PAN HEAD SELF-DRILLING SCREW H900 1
P TOWEL BAR KIT HBCB 1
TOWEL BAR BRACKET H920 4
8-32 X 3/8 TRUSS HEAD SCREW H430 8
DESCRIPTION KEY PART
FRAME PACKAGE
HARDWARE BAG
QTY
