Coral Industries Regal Swing Door (1/4 Frameless) - 4FJ User Manual
Page 3
4FJ-P 8/08
8A x 3/8 Truss Head Screw
(H470 - Used for securing Magnetic
and Hinge Door Stops)
K
8A x 1 Pan Head Screw
(H475 - Used for Jambs)
J
OUTSIDE OF SHOWER
A855
SILL
V001
VINYL DRIP SWEEP
HKMAGCH
MAGNETIC
CATCH KIT
A951
MAGNETIC
DOOR STOP
H470
TRUSS
HEAD
SCREW
H002
ANCHOR
J
H475
PAN
HEAD
SCREW
B
A942
JAMB
D
G
A
K
C
L
HTG6
PUSH /
PULL
HANDLE
KIT
F
V678
VINYL
DOOR SEAL
V
Care should be taken when standing raw glass on its edge. Glass may shatter if corners are bumped or edge is rested
on a rough floor surface. Cardboard, wood blocks, or a similar surface is a safe resting surface for glass.
