PARTS LIST
A SILL A855 1
B JAMB A942 2
C MAGNETIC DOOR STOP A951 1
D VINYL DRIP SWEEP V001 1
V VINYL DOOR SEAL V678 1
J 8A X 1 PAN HEAD SCREW H475 8
K 8A X 3/8 TRUSS HEAD SCREW H470 8
L ANCHORS H002 8
F PUSH/PULL HANDLE KIT HTG6 1
PLASTIC WASHER 4
EXTERIOR PULL HANDLE 1
INTERIOR PULL HANDLE 1
BUSHING 2
HANDLE CONNECTOR SCREW 2
G MAGNETIC CATCH KIT HKMAGCH 1
MAGNET HOLDER WITH MAGNET HMAH / HG92 1
METAL SLIDE HA75 1
HANDLE VINYL V208 1
DESCRIPTION KEY PART QTY
FRAME PACKAGE
HARDWARE BAG
TOOLS
NEEDED
1/8" Drill Bit
3/16" Drill Bit
(3/16" Masonry Bit for
Ceramic Tile)
Pencil
Measuring Tape
Hacksaw
Phillips Screw Driver
Silicone Caulk
File
Drill
Level
Masking Tape
Before starting installation of your new enclosure, carefully read all instructions
and lay out parts to become familiar with their identity.
USE OF ANCHORS
Anchors are furnished with every enclosure. However, the use of anchors is not recommended when attaching your enclosure
to a fiberglass unit or wall surrounds with board reinforced mounting areas. Mounting holes in this case should be drilled with
an 1/8" drill bit.
Mounting this unit on tile requires the use of anchors. Special care must be taken not to crack the tile. Before drilling holes in the
tile, lightly chip glazed surface of tile at the desired locations. Drill holes using a 3/16" masonry drill bit. Insert anchors into the
holes making certain that ring on large end of anchor meets the surface of the tile.
CLEANING
SEALING
Seal unit by caulking along outside of enclosure where metal and bath meet, especially where sill meets threshold. If desired, caulk
inside of enclosure where jambs meet walls.
Cleaning and care of your enclosure is important to its lasting beauty. A nonabrasive liquid cleaner is recommended.
Never use scouring powder or pads.
CAUTION
Do not attempt to cut mirrors or glass used in this enclosure. Tempered glass and mirrors will shatter if cut.
Care should be taken when standing raw glass on its edge. Glass may shatter if corners are bumped or edge is rested on a
rough floor surface. Cardboard, wood blocks, or a similar surface is a safe resting surface for glass.
