10

STROBE LIGHTING CONNECTIONS

POWER CONNECTION
For all configurations the strobe power supply(s) will be powered by the #16AWG RED, and/or RED/BLK wires. For 2 or 4 head
configurations, one wire will be used, 6, 8, 10 and 12 head configurations will use two wires. These wires supply power to each
strobe power supply. All user switches and wiring connected to the RED,RED/BLK and or RED/WHT wires must be rated for a
minimum of 10 Amps and fused at a maximum of 15 Amps for each wire used.

Flash Patterns - All power supplies offer "Quad Flash" and "Random Flash".The flash patterns are controlled by jumpers on
the power supply and can be changed by first removing the power supply from the lightbar and then setting the jumpers.Refer
to the following tables:

Rear Only Flash Pattern

Connect the RED and/or RED/BLK wire in the 16 wire cable to +12 VDC through a user supplied switch.

4/6 Head: Rear inboard and outboard strobes on each side will flash at a minimum rate of 70 FPM

(flashes per minute).
2 Head: If rear inboard strobes are present, strobes will flash at a minimum rate of 70 FPM.

Alternating Flash Pattern

Connect the RED and/or RED/BLK wire and the GREEN wire in the 16 wire cable to +12 VDC through a user supplied
switch. This mode overrides REAR ONLY MODE.
4/6 Head: Front and Rear inboard and outboard strobes on each side will flash at a minimum rate of
70FPM (flashes per minute).
2 Head: Front and rear inboard strobes will flash at a rate of 70 FPM.

Pursuit Flash Pattern

Connect the RED and/or RED/BLK wire and the GRN/BLK wire in the 16 wire cable to +12 VDC through
a user supplied switch. This mode overrides ALL OTHER MODES.
4/6 Head: Front inboard and outboard strobes on each side will flash at a minimum rate of 70 FPM.
2 Head: If front inboard strobes are present, strobes will flash at a minimum rate of 70 FPM.

6-Head Flash Patterns (FIG.9)

Jumper

Quad

Random

Jumper

Quad

Random

J9

J36

J31

2 - 3

1 - 2

2 - 3

2 - 3

2 - 3

1 - 2

PSE 490E (FIG.9A)

YELLOW

Quad

Random

N/C

+12

4-Head Flash Patterns (FIG.9)
