67XXU USB/Serial Scale Service Manual 21
3.3 Mounting
l
Bracket
l
Remote (optional cable required)
l
Column (option kit required)
3.4 Power Supply
l
AC Adapter: 7-9VDC, ≥500mA, center positive
l
USB power supply if USB interface is installed
l
Work current: ≤15mA (with backlight off, and no load cells)
m
≤30mA (with backlight on, and no load cells)
m
≤50mA (with backlight on and one 350 load cell)
3.5 Display
l
51/2-digit,7-segment , 0.58" (15mm) LCDs
3.5.1 Keypad
l
4 push buttons
3.5.2 Environment
3.5.3 Load Cell Excitation
3.6 Approvals
Working temperature -10°C to 40°C
Storage temperature -20°C to 70°C
Humidity 10 to 90% RH without condensation
Voltage 5VDC
Max. Current 20mA
NTEP 13-074
Measurement Canada AM-5912C
