Salter Brecknell 750 Series - Manual (Page 41)

xli
APPENDIX D: DISPLAYED ERROR CODES
CODE MODE MEANING / POSSIBLE SOLUTION
ˆˆˆˆˆˆ Normal Operating
Mode Gross Overload. A weight greater than the rated capacity has been
applied to the scale. Remove the weight from the platter or try re-
calibrating the scale. Otherwise, check for a bad load cell connection or
possible load cell damage due to overloading.
Err 0 Span Calibration
Mode (F17) Keyed-in weight value is less than 1% of full-scale capacity. Use a larger
test weight or check keyed-in value.
Err 1 Span Calibration
Mode (F17) Keyed-in weight value is larger than full-scale capacity. Use a smaller test
weight or check keyed-in value.
Err 2 Span Calibration
Mode (F17) There is not enough load cell signal to produce the internal counts
necessary to properly calibrate the scale. First check all load connections.
Use F16 mode to view internal counts. See Appendix C for more
information.
Err 3 All Modes Non-volatile memory read error. One or more setup parameters have
been lost.
Err 4 All Modes Non-volatile memory write error. Indicator needs service.
Err 5 Key-in Span
Calibration Mode
(F20) You have attempted to enter a zero value for C1. Enter a known
calibration value greater than zero.
Err 7 Initialization No reading from the ADC. Make sure there is a load cell(s) connected to
the indicator at start-up.
Err 9 Normal Operating
Mode Span calibration value has been lost. Re-calibrate the scale.
Err 10 Initialization or Setting
Code Entry Indicator cannot read serial number. Indicator must be returned for
service.
Err 11 Initialization Serial number mismatch. Re-enter setting code from product ID tag.
Err 12 Initialization or Setting
Code Entry Invalid setting code. Re-enter proper setting code from product ID tag.
Err 13 Setting Code Entry Non-volatile memory is in write-protect mode. Toggle position of
Setup/Calibration Switch or JP2 jumper (See Chapter 3).
Note: Contact Service Department at Salter Brecknell for instructions on how to re-enter setting code.
