1-1
CHAPTER 1: INTRODUCTION TO THE 200 SERIES DIGITAL INDICATORS
The 200 Series Digital Indicator is a general purpose, industrial grade weight indicator. Five models are
currently available, distinguishable by display type, enclosure type and power supply. Table 1-1 shows
the 200 Series product matrix.
All models operate identically, can readout up to 50,000 display divisions and can supply enough current
for up to 4-350
Ω load cells. All setup parameters may be entered via the front panel keys, including
calibration.
For certain models, an internal 6V rechargeable battery is available as the primary power source. The
external power supply with these units functions as a charger for the rechargeable battery. The power
supply may also be used as the main power supply.
If your Model 200 Series Digital Indicator is part of a complete floor scale or has been installed for you,
you may skip to Chapter 7 for operating instructions. Prior to using the indicator, please read this chapter
carefully and completely. Store the manual in a safe and convenient place so it will be available if you
have questions concerning the operation of the scale.
If you are an installer, the indicator's installation and wiring instructions are found in Chapter 2. The
indicator contains two main setup menus: The Setup (“F”) menu, which configures the indicator to your
weigh platform and the User (“A”) menu, which configures the serial communication port and enables
some user options. Chapter 3 gives an overview and explains how to use the five front panel keys to
maneuver and save settings in both menus. Chapters 4 and 5 explain the Setup and User Menu options,
respectively. Chapter 6 covers system calibration. Prior to installing the indicator, please read this manual
carefully and completely. Store the manual in a safe and convenient place so it will be available if you
have questions concerning the setup and operation of the scale.
MODEL DISPLAY
TYPE 1
ENCLOSURE
TYPE 2
POWER SOURCE
200 LCD ABS AC adapter - 12 VDC, 500 mA
200E LED ABS AC adapter - 12 VDC, 500 mA
200ES LED Stainless Steel 110/220 VAC, 50/60 Hz 3
200BW LCD ABS 6 x “C” (UM-2) batteries
200SL LCD Stainless Steel Internal 6V battery
TABLE 1-1: 200 Series Product Matrix
1 LCD stands for Liquid Crystal Display. LED stands for Light Emitting Diode.
2 All ABS enclosures are NEMA 12 rated. All stainless steel enclosures are NEMA 4X rated.
3 Earlier models shipped with a 12 VDC, 500 mA AC adapter.
