MODEL 227
OPERATION MANUAL
Doc # 740063 Rev E
TABLE OF CONTENTS
SECTION DESCRIPTION PAGE
SECTION V OPERATION
5.0 Introduction 5.1
5.1 Initial Power-On 5.1
5.2 Use of Next/Prev 5.2
5.3 Weld Schedule Selection 5.3
5.4 Pass Advance 5.4
5.5 Viewing Function Values 5.6
5.6 Overriding Function Values 5.6
5.7 Set Up Functions 5.7
5.8 Remote Pendant Operation 5.11
5.9 Rotation Calibration 5.14
5.10 Wire Feed Calibration 5.15
5.11 Manual Advance Function 5.16
5.12 Welding Operation 5.17
5.13 Printer Operation 5.18
SECTION VI PROGRAMMING
6.0 Introduction 6.1
6.1 Create a Weld Schedule 6.1
6.2 Modify a Weld Schedule 6.4
6.3 Copy a Weld Schedule 6.5
6.4 Transfer/Receive a Weld Schedule 6.5
6.5 Delete a Weld Schedule 6.6
6.6 Program Select Function 6.6
SECTION VII CALIBRATION
7.0 Introduction 7.1
7.1 Equipment Required 7.1
7.2 Current Servo 7.2
7.3 AVC Servo 7.4
7.4 Oscillator Servo 7.5
7.5 General Maintenance 7.7
7.6 System Fault Corrections 7.8
7.7 Error Messages 7.11
7.8 Miscellaneous Maintenance 7.12
SECTION VIII OPTIONS
8.0 Introduction 8.1
8.1 M227/207-CW & M207-CW Cooling Units 8.1
8.2 M-227-EMM External Memory Module 8.3
iv
