MODEL 227
OPERATION MANUAL
Doc # 740063 Rev E
SECTION V - OPERATION
5.3 WELD SCHEDULE SELECTION
2. (continued)
USE SCREEN KEYS TO FIND # PRESS ENTER
OR IF # IS KNOWN ENTER #--- PRESS ENTER
# OD WALL MAT HEAD PASSES *
001 1.500 .065 SS 95 10 *
Instructions are displayed on the upper screen. The first weld schedule in
memory (may not be #001) will be displayed on the lower screen.
3. If you know what weld schedule you want, enter its number using the numeric
keys. The numbers will appear in the --- area as you enter them. If you make a
mistake press CE and start over. When you have entered and verified the
correct number press the ENTER key. After a few seconds your selected weld
schedule will appear on the display. Proceed to step 5.
4. To find the weld schedule you want press the NEXT SCREEN key. The next
weld schedule in memory will be displayed . Continue pressing the NEXT
SCREEN key until the desired weld schedule appears. When the desired
schedule appears, press the ENTER key. After a few seconds your selected
weld schedule will appear on the display.
5. When the weld schedule is called up from memory it will appear on the
screens like this:
# OD WALL MAT HEAD PASS READY
001 1.500 .065 SS 95 01 TO TEST
USE NEXT SCREEN FOR VALUES THEN F KEYS *
TO CHANGE VALUES - USE SEQ START TO WELD
READY TO TEST may say FAULT _______ with an explanation in the _____
space as to what the fault is. The fault must be corrected before proceeding.
5.4 PASS ADVANCE
1. When a Weld Schedule is selected it will always come up showing the first
pass (01). Pressing the NEXT PASS Key will access the second (02) pass (if
there is one).
2. Use the PREV PASS key to return to Pass 01. Continue to use the
NEXT/PREV PASS Keys to access the desired Weld Pass Parameters.
5.4
