Chapter 5: Local Management
5-14 6H128-08 and 6H129-08 User’s Guide
5.5 THE MAIN MENU SCREEN
The Main Menu screen is the access point for all Local Management
screens for the module and the 6C105 chassis.
Figure 5-7 shows the Main
Menu screen.
Figure 5-7 Main Menu Screen
The following explains each Main Menu screen menu item as shown in
Figure 5-7 :
CHASSIS
The Chassis menu item provides access to the Chassis Menu screen,
shown in
Figure 5-8 , which is used to configure the 6C105 chassis and
access current chassis power supply and environmental status. For details
about the Chassis Menu screen, refer to
Section 5.6 .
MODULES
The Modules menu item provides access to the Module Selection screen
that is used to select individual modules in the chassis for management
purposes. For details about the Module Selection screen, refer to
Section 5.12 .
Main Menu
2269_91
6C105 LOCAL MANAGEMENT
CHASSIS
EXIT
MODULES
RETURN
