Chassis Menu Screen
6H128-08 and 6H129-08 User’s Guide 5-15
5.6 CHASSIS MENU SCREEN
The Chassis Menu screen, Figure 5-8 , provides access to Local
Management screens that allow you to configure and monitor operating
parameters, modify SNMP community names, set SNMP traps, monitor
the 6C105 environmental status, and perform port redirect functions, and
to configure the 6C105 for IEEE 802.1Q operation.
To access the Chassis Configuration screen, use the arrow keys to
highlight the CHASSIS menu item and press ENTER. The Chassis
Configuration screen displays.
Figure 5-8 Chassis Menu Screen
The following briefly explains each screen accessible from the Chassis
Configuration screen:
CHASSIS CONFIGURATION
The Chassis Configuration screen allows the user to configure operating
parameters for the 6C105 chassis. For details, refer to
Section 5.7 .
Chassis Menu
CHASSIS CONFIGURATION
2269_99
6C105 LOCAL MANAGEMENT
RETURN
SNMP COMMUNITY NAMES
SNMP TRAPS
CHASSIS ENVIRONMENTAL
PORT REDIRECT FUNCTION
802.1Q VLAN CONFIGURATION
EXIT
