WIRE FEED WELDER MODEL 196.205690 PARTS LIST
26
No.
Code
Description
Qty
01
WE20569-21690175
Front Plastic Frame
1
02
WE20569-21690176
Back Plastic Frame
1
03
WE20569-21600021
Plastic Hanide
1
04
WE20569-21610014
Front Plastic Foot
1
05
WE20569-21610015
Back Plastic Foot
1
06
WE20569-05000065
Front Panel
1
07
WE20569-33700138
Lower Pane!
1
08
WE20569-33715063
Rear Panel
1
09
WE20569-33720063
Dividing Panel
1
10
WE20569-05000066
Right Upper Panel
1
11
WE20569-05000067
Access Door
1
12
WE20569-22200035
Yellow Power Switch 16A-250V
1
13
WE20569-22205117
Switch 17A
1
14
WE20569-04600054
Complete Fan
1
15
WE20569-04600002
Complete Spool Holder
1
15a WE20569-21800036
Spool Holder Handwheel
1
16
WE20569-22400021
Rectifier PMS 30B F Type
1
17
WE20569-22210014
Thermostat 100° 10A
1
18
WE20569-44120087
Transformer 115V 40x60 AL
1
19
WE20569-22225016
Contactor LXO 110V 10A4NA
1
20
WE20569-44135001
Choke 40x40 AL
1
21
WE20569-44400024
Black Plastic Wire Feeder
1
22
WE20569-22710044
RC. Board E0592.1 R 110V + Fuse "CSA"
1
23
WE20569-04600114
Kit Gas/No Gas Change Board
1
23a WE20569-21800051
Handwheel o30
2
24
WE20569-23000081
Gun 0/8 lOmm^
1
25
WE20569-21690244
Gun Pressure Cover
1
26
WE20569-21605010
Cable Clamp For hole o20
2
27
WE20569-20220018
Power Cable 3x4WG14 m 2.5
1
28
WE20569^3210148
Ground Cable lOmm^
1
29
WE20569-22110025
Ground Clamp 300A
1
30
WE20569-21690001
Gun Grommet on Front Panel
1
31
WE20569-21680310
Wire Speed Knob
1
32
WE20569-21690312
Voltage Settings Knob
1
33
WE20569-22910070
Bulkhead Connector Tube o4
1
34
WE20569-04600141
Wire Feeding Motor
1
35
WE20569-33805001
Wire Feed Roll o9x30 .023-.030 Knurled
1
36
WE20569-21010010
ST-CE Screw for Feed Roll
1
37
WE20569-21590002
Hexagonal L Key
1
38
WE20569-21020018
Self-tapping Screw for Frame
8
39
WE20569-21020006
Self-Tapping Screw for Thermostat
2
40
WE20569-21020039
Self-Tapping Screw for Cabinet
10
41
WE20569-21020038
Self-Tapping Screw for Cabinet
14
42
WE20569-21020037
Self-Tapping Screw for Feet
4
43
WE20569-21020018
Self-Tapping Screw for Trans.&Choke
8
44
WE20569-21030010
Washer for Transformer & Choke
8
45
WE20569-21000005
TE Screw for Choke & Contactor
5
46
WE20569-21035002
Gear Washer for Choke & Contactor
7
47
WE20569-21025029
Hex Nut for Contactor
11
48
WE20569-21030008
Washer for Contactor
4
49
WE20569-21000020
TE Screw for Rectifier & Contactor
6
50
WE20569-21035004
Gear Washer for Contactor Fixing
8
51
WE20569-21025028
Hex Nut for Rectifier & Contactor
6
52
WE20569-21030011
Washer for Rectifier
4
53
WE20569-21025011
Hex Nut for Rectifier
1
54
WE20569-21020011
Self-Tapping Screw for Fan
2
55
WE20569-21030002
TCI Screw for Fan
2
56
WE20569-21025015
Hex Nut for Spool Holder
1
57
WE20569-21020003
Self-Tapping Screw for Pressure Cover
2
58
WE20569-21005017
TCI Screw for Pressure Cover
2
59
WE20569-21005040
Handle Screw
2
60
WE20569-33810095
Iron Pin 05 for Access Door
2
61
WE20569-21690177
Side Panel Clip
1
62
WE20569-21055015
Lock Washer for Clip
1
63
WE20669-77600316
Suggested Settings Label
1
64
WE20569-21905002
Plastic Welding Mask
1
65
WE20569-21905007
Dark Glass for Welding Mask
1
66
WE20569-21905011
Hammer-Brush
1
