Specifications
Video camera recorder
System
Video recording system
Two Rotary heads. Helical scanning
FM system
Audio recording system
Two Rotary head. Helical scanning FM
system
Video signal NTSC color, EIA standards
Usable cassette 8 mm video format cassette (Hi8 or
standard 8 mm)
Tape speed SPmode: Approx. 1.43 cm
(19/32 in)/second
LP mode; Approx. 0.72 cm
(5/16 in)/second
Recording time SPmode 2 hour (E6/P6-120)
Playback time SP mode: 2 hour (E6/P6-120)
LPmode: 4hours(E6/P6-120)
Fast-forward/rewind time
Approx. 6 minutes 30 seconds
(E6/P6-120)
Image device CCD (Char^ Coupled Device)
Viewfinder
Electronic viewfinder (color)
Lens Combined 10 x power zoom lens
f> 6.1 to 61 mm (1/4 to 2 7/16 inches)
(44 to 440 mm when converted to a 35
mm still camera)
F 1.6 to 3.1
Filter diameter 52 mm (21/8 inches)
TTL autofocus system iimer foots wide
macro system
Colour temperature
Auto, HOLD, Indoor ^ 3,200 K,
Outdoor* 5,800 K
Minimum illumination
3 l x ( F 1 . 6 )
illumination range
3Utol00/X)0U
Recommended illumination
More than 1(X) lx
Aperture correction
Auto
Input and output connectors
S video input/output
4-pin mini DIN
Luminance signal; 1 Vp-p, 75 ohms,
unbalanced, sync negative
Chrominance signal; 0.286 Vp-p
75 ohms, unbalanced
Video input/output
Wiono jack, 1 Vp-p, 75 ohms,
unbalanced sync negative
Audio input/output
Phono jacks (2; stereo L and R),
input: -7.5 dBs, input impedance more
thw 47 kilohms
Output; -7J dBs, (at load impedance
47 kilohms) impedance less than 2.2
kilohms
RFUDCOUT Special mini-iack. DC 5 V
Headphones jack
Remote jack
MIC jack
Stereo mini-jack lo 3.5)
Stereo mini-mini-jack (o
25)
Stereo mini-jack, -66 dBs low
impedance with 2.5 to 3 V DC. output
impedance 6.8 kilohms (e 3.5)
General
Power requirements
On battery mounting surface
6.0 V (Battery pack)
7.5 V (AC power adaptor)
9.0 V (Alkaline batteries)
Power consumption
6.5 W (camera recording) including the
viewfinder
Installation Vertically, Horizontally
Operating temperature
0^to40'C(32=Ftol04’F)
Storage temperature
-20K: to 60->C (-4»F to ♦ lOI^F)
Dimensions Approx. 109 x 109 x 216 mm (w/h/d)
(4 3/8x4 3/8x8 5/8 inches)
Mass Approx. 930 g (2 lb) excluding the
battery pack, lithium battery, cassette,
lens cap, jack cover and shoulder strap
Approx. 1,300 g (2 lb 13 oz) including
the battery pack NP-66, lithium battery
CR2025, cassette, lens cap, jack cover
and shoulder strap
Microphone Electret condenser microphone, stereo
type
Supplied accessories
Seepage 5.
AC power adaptor
Power requirements
no-240 VAC*. 50/60 Hz
Power consumption
20W
Output voltage DC OUT: 7.5 V, 1.6 A in operating
mode
Battery charge terminal; 10 V, 1.1 A in
charge mode
Application Sony battery pack NP-66, NP-80,
NP-80D, NP-77H, NP-66H, NP-60D,
NP-55H
Operating temperature
0»Cto40’C(32«Ftol04«F)
Storage temperature
-20n: to + 60X: (-4«F to 140‘F)
Dimensions Approx. 170 x 41.6 x 82 mm (w/h/d)
(6 3/4 X 111 / 16 X 31/4 inches)
including projecting parts and controls
Mass Approx, sio g (18 oz)
* Canadian Standard Association (CSA) certifies 120 V
AC only.
Design and specifications are subject to change without
notice.
