Connecting an MD deck for analog
recording

Make sure to match the color of the plugs and
the connectors. To listen to the sound of the
connected MD deck, press FUNCTION
repeatedly until "MD" appears.

To the input of
the MD deck

To the output
of the MD deck

Connecting outdoor
antennas

Connect the outdoor antenna to improve the
reception.

FM antenna

Connect the optional FM outdoor anterma.
You can also use the TV anterma instead.

Jack type ®

lEC standard socket T

connector
(not supplied)

continued
