5'

(O

|T3 Power zoom lever (p. 14)

m EJECT knob (p. 10)

in viewfinder adjustment ring (p. 12)

CCD-TR514/TR814 only

[T

t

I Eyecup release knob (p. 40)

CCD-TR514/TR814only

n Hooks for shoulder strap (p. 51)

n START/STOP button (p. 11)

|2| STANDBY switch (p. 11)

lU Grip strap (p. 15)

m Cassette compartment (p. 10)

H VIDEO OUT jack (p. 17)

M

RFU DC OUT (RFU adaptor DC out) jack

[2i AUDIO OUT jack (p. 17)

m Jack cover

Wf\

MIC (microphone) jack

Connect an optional external microphone. This jack also accepts a "plug-in-povver" microphone.

in Tripod receptacle (p. 15)

Attach a tripod (not supplied) here.

49
