Identifying the Parts
Ш POWER switch (p. 11, 19)
Display window (p. 54)
CCD-TR99 only
Щ
TIME(NEXT) button (p. 23, 33)
g] DATE(+) button (p. 23, 33)
[U COUNTER RESET button (p. 13)
[6] TITLE button (p. 27)
[7] STEADY SHOT mode switch (p. 28)
CCD-TR99/TR814 only
[8] Eyecup (p. 15)
[9] Viewfinder lens adjustment lever (p. 12)
CCD-TR99/TR714only
Щ Battery mounting surface (p. 9)
[lj] LANC
C
control jack
Connect the LANC C connecting cable to л wired remote control unit such as an editing
controller. In this case, set the COMMA.NDER mode to OFF (p. 29).
C
stands for Local
Application Control Bus sytem. The
C
control jack is used for controlling the tape transport of
\ ideo equipment and peripherals connected to it. This jack has the same function as the
connectors indicated as CONTROL 1. or REMOTE.
Щ
.; (headphones) jack (p. 19)
CCD^TR99 only
ИЗ’ ВАТТ (battery) release knob (p. 9)
