(^Setting Up
Setting up the KV-9PT50
Attaching the TV
You can install the TV to the stand (bracket) in two ways with the
supplied dual mode swiv^el bracket.
To the stand
Caution
Do not install the TV with wet hands, or touch the TV and bracket with wet hands.
H To attach the TV to the stand
1 While holding up the lever, push the slider in the direction of the
arrow.
2
Turn the TV sideways, attach the stand to the TV so that the four
claws of the slider fit in the square-holes on the bottom of the TV.
Square-holes (4)
Claws (4)
Setting up
5EN
