Connecting the Speakers icont)
14
Speaker Installation
With the HT-TX72 front speakers and HT-TX75 front/rear speakers, you have the option of installing the speakers on
Stands, or directly to the Stand Base.
Speaker Components (HT-TX72/HT-TX75 only)
.m
o
SPEAKER STAND STAND BASE Screw (A) Screw (B)
How to Install the Speaker on the Stand
1 Turn the STAND upside-down and connect it to
the STAND BASE.
2 Insert two screws (A) into the two holes marked with arrows
using a screwdriver as shown in the illustration.
3 Insert a screw (B), into the hole on the rear of the Speaker
STAND.
4 Connect the assembled stand to the SPEAKER.
5 Insert another screw (B) into the hole on the rear of the
speaker using a screwdriver as shown in the illustration.
6 This is the SPEAKER successfully assembled with
the Stand.
' Make sure that the speaker is installed on a flat and stable area.
Otherwise it may be easily knocked over.
How to Install the Speaker on the Stand Base
1 Connect the SPEAKER with the STAND BASE.
2 Insert the screw (B) into the hole on the rear of the speaker
using a screwdriver as shown in the illustration.
3 This is the SPEAKER successfully assembled with
the Stand Base.
