EMC39-12 User’s Guide
v
TABLE OF CONTENTS
CHAPTER 1
INTRODUCTION
1.1
Using This Manual....................................................................... 1-1
1.2
Getting Help................................................................................. 1-2
1.3
EMC39-12 Overview ................................................................... 1-2
1.4
EMC39-12 Features .................................................................... 1-3
1.5
EMC39-12 Specifications ............................................................ 1-4
CHAPTER 2
INSTALLATION
2.1
Unpacking the EMC39-12............................................................ 2-1
2.2
Installing the EMC39-12 .............................................................. 2-1
2.2.1
Rack Mounting the EMC39-12........................................ 2-2
2.2.2
Free-Standing Shelf or Tabletop Installation .................. 2-3
2.3
Connecting The EMC39-12 to the Power Source........................ 2-4
CHAPTER 3
CONNECTING TO THE NETWORK
3.1
Connecting a Twisted Pair Segment
To The EMC39-12 ....................................................................... 3-1
3.2
Connecting a Fiber Optic Link Segment...................................... 3-2
3.3
Finishing The Installation............................................................. 3-4
CHAPTER 4
USING THE LANVIEW LEDs
4.1
PWR (Power)............................................................................... 4-1
4.2
XMT (Transmit)............................................................................ 4-1
4.3
RCV (Receive)............................................................................. 4-2
4.4
TPLNK (Twisted Pair Link) .......................................................... 4-2
4.5
FOLNK (Fiber Optic Link) ............................................................ 4-2
APPENDIX A
CABLE REQUIREMENTS
A.1
10BASE-T Twisted Pair Requirements .......................................A-1
A.2
10BASE-FL Single Mode Fiber Requirements ............................A-1
APPENDIX B
TWISTED PAIR WIRING TABLES
B.1
Twisted Pair Wiring From an EMC39-12 To a
Punch Down Block ......................................................................B-2
B.2
Twisted Pair Wiring From a Punch Down
Block to a 10BASE-T Device .......................................................B-4
