EMC39-12 User’s Guide Page 3-1
CHAPTER 3
CONNECTING TO THE NETWORK
This chapter outlines the procedure for connecting the EMC39-12 to your
network.
3.1 CONNECTING A TWISTED PAIR SEGMENT
TO THE EMC39-12
The rear panel of the EMC39-12 has a 50-pin Champ connector. The
configuration outlined in this section explains how to attach a twisted pair
cable to the EMC39-12 and to a 10BASE-T compliant Ethernet device
that has a 50-pin Champ connector (e.g. Cabletron Systems’ ELM or
TPRMIM).
You can also run a 50-pin feeder cable from the EMC39-12 to a punch
down block. The Champ connector supports twelve 10BASE-T, twisted
pair segments.
NOTE
Refer to Appendix B for information about wiring the
EMC39-12 to a punch down block.
