Appendix B: Twisted Pair Wiring Tables
Page B-2 EMC39-12 User’s Guide
TX-21 21 Blue/VioletTX- A42 Blue/Violet TX-
RX+47 47 Violet/OrangeRX+ A43 Violet/Orange RX+
RX-22 22 Orange/VioletRX- A44 Orange/Violet RX-
Port 10
Pin Pin Pin
TX+44 44 Yellow/Brown TX+ A37 Yellow/Brown TX+
TX-19 19 Brown/Yellow TX- A38 Brown/Yellow TX-
RX+45 45 Yellow/Gray RX+ A39 Yellow/Gray RX+
RX-20 20 Gray/Yellow RX- A40 Gray/Yellow RX-
Port 9
Pin Pin Pin
TX+42 42 Yellow/Orange TX+ A33 Yellow/Orange TX+
TX-17 17 Orange/Yellow TX- A34 Orange/Yellow TX-
RX+43 43 Yellow/Green RX+ A35 Yellow/Green RX+
RX-18 18 Green/Yellow RX-
A36 Green/Yellow RX-
Port 8
Pin Pin Pin
TX+40 40 Black/GrayTX+ A29 Black/GrayTX+
TX-15 15 Gray/BlackTX- A30 Gray/BlackTX-
RX+41 41 Yellow/Blue RX+ A31 Yellow/BlueRX+
RX-16 16 Blue/YellowRX- A32 Blue/YellowRX-
Port 7
Pin Pin Pin
TX+38 38 Black/GreenTX+ A25 Black/GreenTX+
TX-13 13 Green/BlackTX- A26 Green/BlackTX-
RX+39 39 Black/BrownRX+ A27 Black/BrownRX+
RX-14 14 Brown/BlackRX- A28 Brown/BlackRX-
Table B-1 EMC39-12 to a Punch Down Block (Continued)
From
EMC39-12 Into and Out of 50
Pin Feeder Cable Into Punch Down
Block
