Appendix B: Twisted Pair Wiring Tables

Page B-6

EMC39-12 User’s Guide

B28 Brown/BlackTX-

2

TX-

2

TX-

2

TX-

Port 6

Pin

Pin

Pin

B21 Black/BlueRX+

3

RX+

3

RX+

3

RX+

B22 Blue/Black RX-

6

RX-

6

RX-

6

RX-

B23 Black/OrangeTX+

1

TX+

1 TX+

1

TX+

B24 Orange/Black TX-

2

TX-

2

TX-

2

TX-

Port 5

Pin

Pin

Pin

B17 Red/BrownRX+

3

RX+

3

RX+

3

RX+

B18 Brown/RedRX-

6

RX-

6

RX-

6

RX-

B19 Red/GrayTX+

1

TX+

1

TX+

1

TX+

B20 Gray/RedTX-

2

TX-

2

TX-

2

TX-

Port 4

Pin

Pin

Pin

B13 Red/OrangeRX+

3

RX+

3

RX+

3

RX+

B14 Orange/RedRX-

6

RX-

6

RX-

6

RX-

B15 Red/GreenTX+

1

TX+

1

TX+

1

TX-

B16 Green/RedTX-

2

TX-

2

TX-

2

TX-

Port 3

Pin

Pin

Pin

B9 White/GrayRX+

3

RX+

3

RX+

3

RX+

B10 Gray/WhiteRX-

6

RX-

6

RX-

6

RX-

B11 Red/BlueTX+

11 TX+

1

TX+

1

TX+

B12 Blue/RedTX-

2

TX-

2

TX-

2

TX-

Table B-2

Punch Down Block to a 10BASE-T Device (Continued)

From Punch Down
Block

To RJ45
Wallplate

Into
Office
Drop

Into
10BASE-T
Device

emc39bk Page 6 Monday, February 12, 1996 4:21 PM
