Additional Information
Specifications
LCD panel
Input signal format
Pin assignment
Pixel efficiency
Resolution
Power requirements
Power consumption
Dimensions ( w / h / d )
Mass
Supplied accessories
Panel type: a-Si TFT Active Matrix
CPD-L133
Picture size: 13.3 inches
CPD-L150
Picture size: 15.0 inches
RGB operating frequency:
£h: 15.625 kHz (625 interlace
signal)
15.75 kHz (525 interlace signal)
30 - 70kHz
fv: 50 Hz — 85 Hz
99.99 %
H: max 1024 dots
V: max. 768 lines
Operation:
AC 100 - 240 V, 5 0 - 6 0 Hz
Input:
DC 12 V (using the AC adaptor)
CPD-L133
Display only: Max. 30 W
Including the AC adaptor:
Max. 42 W
CPD-L150
Display oiUy: Max. 25 W
Including the AC adaptor:
Max. 35 W
CPD-L133
Including the stand:
Approx. 373
X 358 x 165 mm
(14 ^ / 4 X 1 4 ' / 8 X 6 ' / 2 in.)
Monitor only:
Approx. 373
X 272 x 71 mm
(14 ^ / 4 X 10 ^ / 4 X 2 ^/8 in.)
CPD-L150
Including the stand:
Approx. 398
X 366 X 165 mm
(15 ^/4 x1 4 '/2 x6 ' / 2 in.)
Monitor only:
Approx. 398
X 291 x 71 mm
(15 3/4X11 1 /2 X2 7/8 in.)
CPD-L133
Approx. 4.9 kg (10 lb 12 oz)
including the stand
CPD-L150
Approx. 5.3 kg (11 lb) including
the stand
See page 6.
(D0(D(D®
© ( D ® ® ©
Pin No. Signal Pin No. Signal
1 Red 8 Blue Ground
2 Green
(Composite
Sync on Green) 9 DDC + 5V*
10 Ground
11 ID (Ground)
3 Blue
12 Bi-Directional
Data (SDA)*
4 ID (Groimd)
5 DDC Groimd* 13 H. S)mc
6 Red Ground 14 V. Sync
7 Green Ground 15 Data Qock(SCL)*
* Display Data Channel (DDC) Standard of VESA
Design and specifications are subject to change without
notice.
20
