Sony CPD-L150 - Manual (Page 10)

Customizing Your Monitor
Introducing the On-Screen
Display System
Most adjustments are made using the MENU OSD.
To change the on-screen display language, see "Selecting
the On-screen Display Language" (page 8 ).
iiliPHASE
DID PITCH
OCENTER
SS ZOOM
B COLOR
Q LANGUAGE
aOPTION
EXIT
Qoses the MENU OSD.
PHASE
Displays the PHASE OSD. Adjust the phase when the
diaiacteis or pictures appear fuzzy throughout the entire
screen. Adjust the phase after adjusting the pitch.
PITCH
Displa)rs the PITCH OSD. Adjust the pitch when the
characters or pictures are not clear at some parts of the
screen.
CENTER
Displays the CENTER OSD for adjusting the centering of
die picture.
ZOOM
Displays the ZOOM OSD for selecting the picture's display
mode. Select FULL MODE to display the picture using the
entire screen, or select REAL MODE to display the picture at
its actual resolution.
COLOR
Displays the COLOR OSD for adjusting the color
temperatiue.
LANGUAGE
Displays the LANGUAGE OSD for selecting the on-screen
display language.
OPTION
E>isplays the OPTION OSD. You can adjust settings such as
the backlight, OSD position, power saving delay time and
control lock.
Using the Utility Disk
The supplied Utility Disk contains test patterns to be used
for Pitch, Phase, and Centering adjustments.
These test patterns will help you confirm that your
adjustments are correct.
Pitch adjustment
Adjust the Pitch if vertical stripes appear on the screen, or a
part of the screen flickers or blurs.
Adjust the screen so that the bold, vertical lines of the test
pattern disappear.
Phase adjustment
Adjust the Pheise if the entire screen flickers or blurs, or if
horizontal stripes are observed on the screen.
Adjust the screen until the horizontal stripes are at a
minimum.
Centering adjustment
Adjust the Centering if the picture is not centered.
Move the picture up, down, left, or right imtil the red frame
at the perimeter of the test pattern disappears.
1 Set ZOOM to REAL MODE (page 12).
2 Load the supplied Utility Disk and display the test
pattern.
Use die appropriate disk for your computer.
For Windows 95/98
Windows Monitor Information Disk/Utility Disk
For Macintosh
Macintosh Utility Disk
3 Select the pitch, phase, or centering from the
monitor's MENU OSD, and adjust the screen while
viewing the test pattern (pages 11,12).
4 When you have finished, click I end I on the screen to
turn off the test pattern.
10
