Preset and User Modes
This monitor has factory preset modes for the most popular
industry standards for true "plug and play" compatibility.
When a new input signal is entered, the monitor selects the
appropriate factory preset mode and momentcuHy adjusts
the phase calibration to provide a high quality picture to the
center of the screen. The calibration is stored in memory
and is immediately recalled whenever the same input signal
is received.
No.
Resolution Horizontal Vertical
(dots X lines) Frequency Frequency Graphics Mode
1 — 15.625 kHz 50 Hz 6251
2 — 15.75 kHz 60 Hz 5251
3 640 x 350 31.5 kHz 70 Hz MCGA
4 640x400 31.5 kHz 70 Hz NEC PC-98
5 640x480 315 kHz 60 Hz VGA-G
6 640x480 35.0 kHz 67 Hz Macintosh
13" color
7 640 x 480 375 kHz 75 Hz EVGA
8 640x480 435 kHz 85 Hz VESA
9 720x400 315 kHz 70 Hz VGA-Text
10 720x400 37.9 kHz 85 Hz VESA
11 800x600 37.9 kHz 60Hz SVGA
12 800 x 600 46.9 kHz 75 Hz ESVGA
13 800 x 600 53.7 kHz 85 Hz VESA
14 832 x 624 49.7 kHz 75 Hz Macintosh
16" color
15 1024 x 768 48.4 kHz 60 Hz VESA
16 1024x768 56.5 kHz 70Hz VESA
17 1024x768 60.0 kHz 75 Hz EUVGA
18 1024x768 60.2 kHz 75 Hz Macintosh
19" Color
19 1024x768 68.7 kHz 85 Hz VESA
For input signals that do not match one of the factory preset
modes, the digital Multiscan technology of this monitor
performs cdl of the adjustments necessary to ensure that a
clear picture appears on the screen for any timing in the
monitor's frequency range. However, it may be necessary
to fine tune the vertical/horizontal centering. Simply press
the AUTO button or adjust the monitor according to the
adjustment instructions. The adjustments are stored
automatically as a user mode and recalled whenever the
corresponding input signal is received.
Recommended horizontal and vertical timing
conditions
Horizontal sync width duty should be 5.8% or higher of total
horizontal time.
Horizontal blanking width should be 2.5 gsec. or higher.
Vertical blanking width should be 450 gsec. or higher.
Adjusting the monitor's resolution and color
number
Adjust the monitor's resolution and color number by referring to
yom computer's instruction manual. The color number may vary
according to your computer or video board. The color palette
setting and the actual number of colors are as follows:
• High Color (16 bit) —► 65,536 colors
• True Color (24 bit) —► about 16.77 million colors
In true color mode (24 bit), speed may be slower.
