Specifications
On operation
• Operate the camcorder on 6 0 V (battery pack),
7.5 V (AC power adaptor), or 9 0 V (alkaline
batteries).
• For DC or AC operation, use the accessories
recommended in this manual.
• Should any solid ob)ect or liquid tall into the
casing, unplug the camcorder and have it
checked by qualified personnel before
operating it any further.
• Do not hold the camcorder by the viewfinder or
the microphone.
• Avoid rough handling or mechanical shock. Be
particularly careful of the lens.
• Keep the lens cap on the lens when not using
the camera.
• Do not wrap the camcorder and operate it
because heat may build up internally.
• Keep the camcorder away from strong
magnetic fields or mechanical vibration.
• Do not put the camcorder on the sand.
On care
• When the unit will not be used for a long time,
disconnect the power source and remove the
tape. Periodically turn on the power, operate
the camera section and player section, and
play back a tape for about 3 minutes.
• Clean the lens with a soft brush to remove
dust. If there áre fingerprints on it, wipe them
off with a soft doth.
Clean the camcorder body with a dry, soft
cloth, or a soft cloth lightly moistened with a
mild detergent solution Do not use any type of
solvent which may damage the finish.
Note on copyright
Television programs, films, video tapes, and other
materials may be copyrighted. Unauthorized recording
ot such materials may be contrary to the provision of
the copyright laws.
abroad, check the following points.
Power Sources
You can use your camcorder in any country with
the supplied AC power adaptor within 110 V to
240VAC.50/60H2.
Difference in Color Systems
You can view the playback picfure in the
viewfinder. However, if you want to view the
playback picture on a TV, it must be an NTSC
system-based TV. Check the following list, (in
alphabetical order)
NTSC system countries
Bahama Islands, Bolivia, Canada, Central
America, Chile, Colombia, Ecuador, Jamaica,
Japan, Korea, Mexico, Peru, Surinam, Taiwan.
The Philippines, U.S.A., Venezuela, etc.
PAL system countries
Argentina. Australia, Austria, Belgium, Brazil,
China, Denmark, Finland, Germany (Former
West Germany), Great Britain, Holland, Hong
Kong, Italy, Kuwait, New Zealand, Norway,
Paraguay, Portugal. Singapore. Spam, Sweden,
Switzerland, Thailand, Urguay, etc.
SECAM system countries
Bulgaria, France, Guiana, Hungary. Iran, Iraq,
Monaco, Poland, Soviet Union, etc.
Video signal
Usable cassette
Tape speed
Recording lii
Video recording system
Rotary two head. Helical scanning
FM system
Audio recording system
Rotary head, FU system
NTSC color. EIA standards
m video formal cassette
SP mode: Approx 1 43 cm
(
1/16 irch)/sec
LP mode: Approx 0 72 cm
(1/32 inch)/sec
(playback only)
SP mode 2 hours (P6-120)
SP mode: 2 hours (P6 120)
LP mode 4 hours (P$-120)
Fast lofward/rewmd time
Approx 6.5 min. (P6-120)
Image device CCD (Charge Coupled Device)
Viewlirxter Electronic viewfir>der
(black and while)
Combined 8 x power zoom lens
1=8.5 to 68 mm (11/32 to 2’/.
inches), FI.6 wilh macro
Filter diameter: 46 mm
(1 ”/i6 inches)
Auto focus system TTL
Color temperature Automatic, HOLD,
.4 (intjooi) 3.200K,
• (outdoor) 5.800K
Minimum illumination
2 lux
Illumination range 2 lux to 100.000 lux
(0.2 lo 9294 foolcarxfies)
Recommended illumination
More than 100 lux
(9 lootcandies)
Aperture correction Automatic
With back light adjustment
Input And output ooniwctor
Video input/output* Phono |ack, 1 Vp-p. 75 ohms
unbalanced, sync negative
Audio input/oulpul’ Phono )ack.
Input- -7.5 dBs, input impedance
more than 47 kilohms
Output. -7.5 dBs, at Output
impedance less than
1 kilohms
RFU DC OUT Special minijack, 5 V DC
Earphone )ack
Minijack, 8 ohm impedance
Remote jack Stereo mini-mimjack
:h the IN/
Gancral
Power requirements
On battery mounting surface
6.0 V (battery pack)
7 5V (AC power adaptor)
V (alkaline batteries)
Power consumptioi
6 2 W (camera recording) including
the viewfinder
Installation Vertically, horizontally
Operating temperature
0"C to 40"C (32 "F IO104 F)
Storage temperature
-20’C lo *60'C (-4’Fto *140°F)
Dimensions Approx 111 - 139'32t mm
(w/h/d) (4>/i « 5'/?. 12=/. inches)
including the lens hood
Weight Approx i .i kg (2 lb 3 oz| excluding
the battery and cassette
Microphone Electret condenser microphone.
uni directional monaural type
Supplied accessories
See page 4.
n*met* Commander RMT-8M
Remote control system
Infrared control
Command mode VTR 2
Power requirements
3 V DC, 2 size AA batteries
Dimensions Approx 60 « 25 X 123 mm (w/h/d)
(2-’/ b X 1 X 47« inches)
