ITBR001-302 www.twobros.com 2011 Honda CBR250R - 3
1. Remove the seat.
2. Using the supplied velcro, secure the Juice Box Pro to the top of the battery as
shown in Figure A.
Make sure to clean both surfaces with the alcohol swab before attaching.
3. Route the Juice Box Pro harness to the left side of the air box as shown in
Figure B.
Remove the bolt for the air box to allow the harness to be placed on the inside of
the frame. Reinstall the bolt once the harness has been routed.
4. Unplug the stock wiring harness from the fuel injector as shown in Figure C.
FIG
.A
FIG
.B
FIG
.C
bolt
harness
unplug
