Two Brothers Racing Yamaha FZ6R User Manual
V.a.l.e, Fz6r, 2009 yamaha

1.
Make sure the bike is completely cool before
starting the installation. Make sure the bike is
secure on a centerstand or ideally a service lift.
2.
Remove right side fairing.
3.
Remove header flange nuts.
4.
Remove OEM muffler assembly.
5.
Install TBR header pipes, 1-4 number 1 starting on
the left if sitting on the bike, leave loose for now, be
sure to retain stock gasket.
6.
Attach muffler mounting bracket to right side OEM
mounting position using the OEM bolt and supplied
8mm flange nut.
7.
Install left and right collectors using a small amount
of high temp silicone on all slip fit areas.
8.
Attach muffler to TBR slip system using the supplied
X-ring, 6x14mm socket head cap screws and lock
washers that are provided, leave loose for now.
V.A.L.E.
V a r i a b l e a x i s l o c k i n g e x h a u s t
TM
Parts List
IMPORTANT - PLEASE READ CAREFULLY
We recommend that this performance part be installed by a qualified
motorcycle technician. If you have any doubts as to your ability to install this
performance part, please consult with your local motorcycle dealer. Read all
instructions first before starting installation. Make sure the motorcycle and
exhaust system are completely cool before starting the installation. Also,
make sure the bike is secure on a centerstand or ideally a service lift during
installation. Be sure to save all stock components for possible use later.
Installation Instructions
Qty. Description
Part Number
1
M-2 Muffler Canister
005-257-206M
1
Canister Clamp with Rubber Liner
005-2C-113
1
Header Kit
005-25701HK
1
HARDWARE KIT
005-257-3
2
X-Ring (half)
005-7-2-3
1
FZ6R Bracket
005-257-B
1
8x16mm Flange Bolts
005-FB816
2
8mm Flange Nuts
005-FN8
4
6x14mm Socket Head Cap Screws
005-SH614
4
6mm Split Lock Washer
005-WL6
1
Permatex Hi-Temp Sealant
031-P22072
1
T20 Torx Hex Key
005-9-15820
1
5mm Ball End Hex Key
005-9-18610
1
TBR Sticker Kit
015-10212
2009 Yamaha
FZ6R
V.A.L.E.™ Full Exhaust System with M-2 Exhaust Canister
Part # 005-2570106V, 005-2570107V, 005-2570108V
Warranty Information
two brothers racing products are intended for closed course competition purposes only, and therefore are
sold “as is” without warranty. two brothers racing specifically disclaims any warranties of merchantability
or fitness for a particular purpose and disclaims all responsibility for consequential and incidental damages
or any other losses arising from the use of these products or parts.
