Taylor-Wharton 24K w/ AutoTend - Manual (Page 44)

Fully Auto
-MOWDEN MARK 1
-GE MARK 2
-PCR
CONTROLLER 5140-1128 5140-1145 5140-11
THERMOCOUPLE R06K-9C46 N/A R08K-9C
SENSOR ASSEMBLY R06K-9C44 5140-1147 R08K-9C
REMOTE ALARM PLUG R06K-8C20 R06K-8C20 NOTE 1
SENSOR TUBE1 R23K-9C96 R23K-9C96 R23K-9C
SENSOR TUBE PLUG R10K-9C69 R10K-9C69 R10K-9C
TRANSFORMER N/A 5140-1146 N/A
ELECTRIC PANEL R06K-9C25 5140-1148 R08K-9C
LID SWITCH N/A 5160-1042 N/A
CABLE, LID SWITCH N/A R23K-9C71 N/A
PLUMBING ASSEMBLY N/A R23K-8C61 R17K-8C
-SOLENOID VALVE2 R06K-9C61 6999-9021 R08K-9C
-RELIEF VALVE, 100 psi 6913-9077 6913-9077 6913-90
FILTER ASSEMBLY 7631-1075 7631-1075 7631-10
TEMP. GRADIENT SUP.3 R20K-8C70 R20K-8C70 R20K-8C
Note 1 – Radio Shack Park Number 274-001 Microphone jack.
Fully Auto
-MOWDEN MARK 1
-GE MARK 2
-PCR MARK 2LT
-PCR MARK 3
-GE KRYOS
-PCR
CONTROLLER 5140-1128 5140-1145 5140-1131 R08K-9C00 5140-1143 5140-1166
SENSOR ASSEMBLY R06K-9C44 5140-1147 R08K-9C49 R08K-9C01 5140-1137 5140-1163
THERMOCOUPLE R06K-9C46 N/A R08K-9C51 R08K-9C51 R08K-9C51 R08K-9C51
REMOTE ALARM PLUG R06K-8C20 R06K-8C20 NOTE 1 R06K-8C20 R06K-8C20 R06K-8C20
SENSOR TUBE
1
R23K-9C96 R23K-9C96 R23K-9C96 R23K-9C96 R23K-9C96 R23K-9C96
SENSOR TUBE PLUG R10K-9C69 R10K-9C69 R10K-9C69 R10K-9C69 R10K-9C69 R10K-9C69
TRANSFORMER N/A 5140-1146 N/A R08K-9C04 5140-1139 R08K-9C04
ELECTRIC PANEL R06K-9C25 5140-1148 R08K-9C47 R08K-9C02 5140-1142 5140-1167
LID SWITCH N/A 5160-1042 N/A 5160-1042 5160-1042 5160-1042
CABLE, LID SWITCH N/A R23K-9C71 N/A R23K-9C71 R23K-9C71 N/A
PLUMBING ASSEMBLY N/A R23K-8C61 R17K-8C61 R23K-8C62 R24K-8C52 R10K-8C64-R
-SOLENOID VALVE
2
R06K-9C61 6999-9021 R08K-9C48 6999-9021 6999-9021 6999-9021
-RELIEF VALVE, 100 psi 6913-9077 6913-9077 6913-9077 6913-9077 6913-9077 6913-9077
FILTER ASSEMBLY 7631-1075 7631-1075 7631-1075 7631-1075 7631-1075 7631-1075
TEMP. GRADIENT SUP. R10K-9C84 R10K-9C84 R10K-9C84 R10K-9C84 R10K-9C84 R10K-9C84
TGS STRAPS* R06K-9C20 R06K-9C20 R06K-9C20 R06K-9C20 R06K-9C20 N/A
3
Note 1 – Radio Shack Park Number 274-001 Microphone jack.
*No straps on 10K or 18K
1
May require field cut-to-length
2
May require electrical bolt-end-connectors for 18 gauge wire.
3
Includes TGS straps
