APPENDIX
Bottom
■
USB Cradle
Front
Back
bq Speaker (page 147)
br Battery/Memory Card Slots (pages 36, 48)
bs Cradle Contact (page 38)
bt Tripod Hole
Use this hole when attaching to a tripod.
bq
br bs bt
1 Camera Contact (page 38)
2 USB Lamp
(pages 224, 241, 260)
3 [USB] Button
(pages 211, 224, 241)
4 [PHOTO] Button
(pages 153, 155)
5 [CHARGE] Lamp
(pages 38, 260)
6 [AV OUT] (AV output port)
(page 154)
7 [ ] (USB) Connector
(pages 209, 223, 240)
8 [DC IN 5.3V] (External
Power) Terminal (page 37)
3 2
1
5
4
8
6
7
