Dell Inspiron 17 (N7010, Mid 2010) - Manual (Page 58)

2. Place the subwoofer assembly on the computer base.
3. Replace the three screws that secure the subwoofer assembly to the computer base.
4. Connect the subwoofer cable to the connector on the system board.
5. Replace the palm rest (see Replacing the Palm Rest ).
6. Replace the keyboard (see Replacing the Keyboard ).
7. Replace the optical drive (see Replacing the Optical Drive ).
8. Follow the instructions from step 5 to step 7 in Replacing the Hard Drive .
9. Replace the module cover (see Replacing the Module Cover ).
10. Replace the battery (see Replacing the Battery ).
Back to Contents Page
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
