Display Functions
Wireless Networking Technology Function
Display Switch
Power Management
Microsoft Windows Logo Key Functions
To adjust keyboard operation, such as the character repeat rate, open the Control Panel, click Printers and Other Hardware, and click Keyboard. For
information about the Control Panel, see the Microsoft® Windows® Help and Support Center. To access the Help and Support Center, see
Windows Help and
Support Center .
Touch Pad
The touch pad detects the pressure and movement of your finger to allow you to move the cursor on the display. Use the touch pad and touch pad buttons as
you would use a mouse.
l To move the cursor, lightly slide your finger over the touch pad.
Enables and disables wireless 802.11 networking technology. It does not disable the Bluetooth wireless technology.
Allows you to switch the currently active display from the LCD to a connected CRT or external monitor, projector, or TV. To select a display, press
and hold and press until the desired display is highlighted, then release.
Activates a power management mode. You can reprogram this keyboard shortcut to activate a different power management mode using the
Advanced tab in the Power Options Properties window.
Puts the system into hibernate mode. Dell QuickSet is required. See Dell QuickSet .
Windows logo key and Minimizes all open windows.
Windows logo key and
Restores all minimized windows. This key combination functions as a toggle to restore minimized windows following the use of
the Windows logo key and key combination.
Windows logo key and Runs Windows Explorer.
Windows logo key and Opens the Run dialog box.
Windows logo key and Opens the Search Results dialog box.
Windows logo key and
Opens the Search Results-Computer dialog box (if the computer is connected to a network).
Windows logo key and
Opens the System Properties dialog box.
1 touch pad 2 scroll zone 3 touch pad buttons
