Page 5: Microphone connector

security cable slot —

Lets you attach a commercially available antitheft device to the computer. For more information, see the instructions included with the

device.

USB 2.0 connectors (2)

headphone connector —

Attach headphones to the

connector.

microphone connector —

Attach a microphone to the

connector for voice or musical input into a sound or telephony program.

wireless connection button —

Puts the computer into discover mode to connect the wireless keyboard and mouse with the system using Bluetooth wireless

technology if the pairing is lost. For more information, see

Pairing the Keyboard

and

Pairing the Mouse

display latch release —

Slide these latches forward to open your display.

Right View

IEEE 1394 connector (firewire) —

Connects devices supporting IEEE 1394 high-speed transfer rates, such as some digital video cameras, hard drives, and

optical drives.

media memory card reader —

Provides a fast and convenient way to view and share digital photos, music, and videos stored on a media memory card. The

media memory card reader reads the following digital media memory cards:

Secure Digital (SD) card/SDIO

MultiMediaCard (MMC)

Memory Stick (MS)

Memory Stick Pro

xD-Picture Card

With a commonly available adapter, the memory card reader also reads the following digital media memory cards:

MiniSD

RSMMC

(Bluetooth wireless technology)

NOTICE:

Before you buy an antitheft device, ensure that it will work with the security cable slot.

Connects USB devices, such as a mouse, keyboard, or printer.
