System Setup: Dell XPS 730/730X Service Manual
file:///C|/Users/santhosh_v/Desktop/7/SM_en/system_s.htm[9/5/2013 11:46:47 AM]
Cache L2 Displays the processor L2 cache size.
Standard CMOS Features
System Time (hh:mm:ss) Displays the current time.
System Date (mm:dd:yy) Displays thecurrent date.
SATA 1 Displays the SATA 1 drive integrated in
the system.
SATA 2 Displays the SATA 2 drive integrated in
the system.
SATA 3 Displays the SATA 3 drive integrated in
the system.
SATA 4 Displays the SATA 4 drive integrated in
the system.
SATA 5 Displays the SATA 5 drive integrated in
the system.
SATA 6 Displays the SATA 6 drive integrated in
the system.
SATA 7 Displays the SATA 7 drive integrated in
the system.
SATA 8 Displays the SATA 8 drive integrated in
the system.
IDE Master Displays the IDE Master installed in the
system.
IDE Slave Displays the IDE Slave installed in the
system.
Advanced BIOS Features
Boot up NumLock Status Select power-on state for num-lock.
ACPI APIC support Include ACPI APIC table pointer to RSDT
pointer list.
Boot Configuration Features
1st Boot Device Displays the first boot device.
2nd Boot Device Displays the second boot device.
Hard Disk Drives Sets the hard drive boot priority. The
items displayed are dynamically updated
according to the hard drives detected.
CD/DVD Drives Sets the CD/DVD drive boot priority. The
items displayed are dynamically updated
according to the hard drives detected.
CPU Configuration
XD Bit Capability Enable XD Bit Capability to allow the
processor to distinguish between the bits
of code that should be executed and the
ones that cannot be executed.
C1E Support The Enhanced Halt State (C1E) reduces
the processor speed down to its lowest
