Replacing Drives: Dell XPS 730/730X Service Manual
file:///C|/Users/santhosh_v/Desktop/7/SM_en/drives.htm[9/5/2013 11:46:36 AM]
Replacement:
1 hard drive 2 hard drive bracket
3 hard drive cage
6. Verify that the hard drive bay is empty and unobstructed.
7. Slide the hard drive into the hard drive bay until it clicks securely into place.
1 hard drive 2 hard drive bay
CAUTION: Ensure that all connectors are properly cabled and firmly seated.
8. Connect the power cable to the hard drive.
9. Connect the hard drive data cable to the hard drive.
