Replacing the Processor: Dell XPS 730/730X Service Manual
file:///C|/Users/santhosh_v/Desktop/7/SM_en/processo.htm[9/5/2013 11:46:41 AM]
1 processor cover 2 processor
3 socket
4 release lever
CAUTION: When removing or replacing the processor, do not touch any of the pins inside the socket or
allow any object to fall on the pins in the socket.
7. Lift the processor to remove it from the socket, place it aside in a safe and secure place.
Leave the release lever extended in the release position so that the socket is ready for the new processor.
8. Unpack the new processor, being careful not to touch the underside of the processor.
Installing the Processor
