56 CHAPTER 7: BASIC SPECIFICATIONS
Computer Model
Alienware M17x-R2
Dimensions
Height
(Front to Back)
51.31 mm to 53.59 mm (2.02 inches to 2.11 inches)
Width 405.89 mm (15.98 inches)
Depth 321.31 mm (12.65 inches)
Weight with 9-cell battery
(starting at)
5.3 kg (11.8 lb)
NOTE: The weight of your laptop will vary
depending on the configuration ordered and the
manufacturing variability.
Processor and System Chipset
Processor
Intel ® Core™ i7
Intel Core i5
System chipset Mobile Intel PM55
Memory
Connectors
two internally-accessible SODIMM sockets
Capacities 2 GB and 4 GB memory modules
Memory types DDR3 1067 MHz, 1333 MHz
(dual-channel configurations)
NOTE: DDR3 1333 MHz memory is supported only
on computers with an Intel Core i7 processor.
Memory configurations
possible
4 GB, 6 GB, and 8 GB
Ports and Connectors
IEEE 1394 A
one 4-pin serial connector
Network adapter one RJ45 connector 10/100/1000 Mbps
USB four 4-pin USB 2.0-compliant connectors
eSATA/USB combo one 11-pin eSATA/USB combo connector
VGA one 15-hole connector
DisplayPort one 20-pin connector
HDMI one 19-pin connector
Audio one microphone connector,
three stereo headphone/speaker connectors
