Display Bezel
Dell™ Latitude™ E5400 Discrete Service Manual
Removing the Display Bezel
1.
Follow the procedures in
Before Working Inside Your Computer
.
2.
Remove the
battery
from the computer.
3.
Remove the
access panel
from the computer.
4.
Remove the
hinge cover
from the computer.
5.
Remove the
keyboard
from the computer.
6.
Remove the
display assembly
from the computer.
7.
Remove the
palm rest
from the computer.
8.
Remove the
system board
from the computer.
9.
Gently pry the display bezel from the display assembly by tucking your fingers under one edge of the bezel and working your way around the entire
bezel until it is completely free.
10.
Remove the display bezel from the computer.
Back to Contents Page
WARNING:
Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE:
You may need to install Adobe Flash Player from Adobe.com in order to view the illustrations below.
