Specifications
Dell™ Latitude™ E5400 Discrete Service Manual
NOTE:
Offerings may vary by region. For more information regarding the configuration of
your computer, click Start
(or Start in Windows® XP)®
Help and Support, and then
select the option to view information about your computer.
Processor
Processor type
Intel® Core™ 2 Duo processors
Intel Celeron® processor (Socket P)
Bus speed
maximum, 1066 MHz for Intel Core 2 Duo
L1 cache
32 KB
L2 cache
1 MB
System Information
System chipset
Mobile Intel GE45 Express chipset
Data bus width
64 bits
DRAM bus width
Dual-channel (2) 64 bit buses
Processor address bus width
32 bits
Flash EPROM
16 MB
PCI bus
32 bits
3-in-1 Memory Card Reader
Cardbus controller
Ricoh R5C847
Connector
3-in-1 combo card connector
Cards supported
SecureDigital (SD), SDIO, MultiMediaCard (MMC)
Memory
Memory module connectors
two DIMM sockets
Memory module capacities
512 MB, 1, 2, 3, or 4 GB capable
Memory type
DDR II 667 MHz and 800 MHz SDRAM
Minimum memory
512 MB
Maximum memory
8 GB
Ports and Connectors
PC Card
Type I/II PC Card connector
Audio
microphone connector, and stereo headphone/speakers
connector
IEEE 1394
4-pin connector
Mini-Card
One full Mini-Card and one half Mini-Card slot
Modem
Optional RJ-11 connector
Network adapter
RJ-45 connector
Video
S-video (supports S/PDIF adapter), VGA
USB
four USB connectors
E-family docking
144-pin docking connector
