Dell INSPIRON 2600 User Manual
Page 5
2.
Insert the latch plate in the bottom case.
3.
Install the new latch button from behind the bottom case, ensuring that the latch button and latch plate screw holes are properly aligned.
To prevent the latch assembly from coming loose, apply pressure to the latch plate and spring while replacing the latch button.
4.
Replace and tighten the M2 x 4-mm screw that secures the latch button to the bottom case.
Ensure that the newly installed latch moves smoothly and freely when pushed and released.
Back to Contents Page
