Table 3. IRQ Line Assignments

Memory Allocations

Table 4

provides a map of the conventional memory area. When the microprocessor or a program addresses a location within the conventional

memory range, it is physically addressing a location in main memory.

Table 4. Conventional Memory Map

Table 5

provides a map of the upper memory area. Some of these addresses are dedicated to various system devices, such as the system/video

basic input/output system (BIOS). Others are available for use by expansion cards and/or an expanded memory manager (EMM).

When the microprocessor or a program addresses a location within the upper memory area, it is physically addressing a location within one of
these devices.

Table 5. Upper Memory Map

NOTES: Installed devices cannot share the same COM port address. The default address of your computer's serial port is COM1.

To view IRQ line assignments in the Microsoft® Windows® 95 and Windows 98 operating systems, click the Start button, point to
Settings, and click Control Panel. Double-click the System icon. Select the Device Manager tab, and then double-click Computer.

IRQ Line Reserved/Available

IRQ0

Reserved; generated by the system timer

IRQ1

Reserved; generated by the keyboard controller to signal that the keyboard output buffer is full

IRQ2

Reserved; generated internally by the interrupt controller to enable IRQ8 through IRQ15

IRQ3

Available for use by a PC Card unless the integrated serial port or infrared port is configured for COM2 or COM4

IRQ4

Available for use by a PC Card unless the integrated serial port or infrared port is configured for COM1 (the default) or COM3

IRQ5

Available for use by the audio controller

IRQ6

Generated by the diskette drive controller to indicate that the diskette drive requires the attention of the microprocessor

IRQ7

Available for use by a PC Card or audio controller if the parallel port is disabled

IRQ8

Reserved; generated by the system I/O controller's RTC

IRQ9

Reserved

IRQ10

Available for use by a PC Card or audio controller unless the C/Port Family APR or C/Dock Family Expansion Station is attached

IRQ11

Available for use by USB, PC Card, video controller, and audio controller

IRQ12

Reserved; generated by the keyboard controller to indicate that the output buffer of the touch pad or external PS/2 mouse is full

IRQ13

Reserved; generated by the math coprocessor

IRQ14

Reserved; generated by the hard-disk drive to indicate that the drive requires the attention of the microprocessor

IRQ15

Reserved; generated by CD-ROM drive in the external media bay to indicate that the drive requires the attention of the
microprocessor

NOTE: To view memory allocations in Windows 95 and Windows 98, click the Start button, point to Settings, and click Control Panel.
Double-click the System icon. Click the Device Manager tab, and then double-click Computer.

Address Range

Use

0000h-003FFh

Interrupt vector table

00400h-004FFh

BIOS data area

00500h-005FFh

MS-DOS

® and BASIC work area

00600h-9FBFFh

User memory

Address Range

Use

0009FC00-0009FFFF

PS/2-mouse data area

000A0000-000BFFFF

Video RAM

000C0000-000CBFFF

Video BIOS

000CC000-000CDFFF

PC Card

000F0000-000FFFFF

System BIOS
